QDF Model Series of Photoelectric Error-correction High-speed Laminating Machine Views:2873



Feature:

Machines in this series are suitable for reel-shape materials such as BOPP, PET, CPP, luminum  foil, and  paper, 2-layer  repetitious  laminating, high strength production, producing high-quality compound materials  with  high freshness preserving, and boiling & steaming resistance.
1. Double frequency conversing synchronic timing is adopted for entry port of main machine, making more stable operation
2. Two means of glue applying, cobwebbing roll sizing and rubber roll gluing
3. Top air style oven open, initiative guiding roll in oven
4. 4-sect heating in drying tunnel, possible to control temperature by segments
5. Photoelectric error correction for unreeling, with automatic tension
6. Reeling and unreeling by tumbling dual-station mechanism, realizing auto material change
    without machine halt.
7. Oil warming system for composite reel, constant temperature control

Main Technical Variables:

Model BGF-600 BGF-800 BFG-1000
Width of laminating > 600mm 800mm 1000mm
Laminating stratification 2层 2层 2层
Laminating speed 10-120m/min 10-120m/min 10-120m/min
Diameter of Roll material Φ800mm Φ800mm Φ800mm
Oven temperate 120℃ 120℃ 120℃
Total Power 44kw 48kw 52kw
Weight 7500kg 8200kg 8900kg
Overall Dimension 9600×2400×3300mm 9600×2650×3300mm 9600×2850×3300mm
