DFCY-4-5-6Automatic Syphon Making Machine Views:1681





Characteristic:

Automatic flexible dringing straw making machine provides new levels of performance for the production of flexible straws.The entire operation,form product in-feed and forming to finished product out-feed,is automatically performed requiring the operator to add the material only.
    The straight strawa suplied in the hopper at the top of machine,are fed one by obe into main drum of the machine and clamped by two mechanical catches.As the main drum rotates,the straw passes theough two rotary dies to receive die-pressed effect,is then compressed with two catches to form flexible .And delivered to the output coneveyor automatically.
    The main drum always carries 12 straws in successive and different operation .This development represents a giant step forword for higher productin of flexible straws.

Application Range:
High efficiency and high production rate.
Automatic counter,alarm in pre-set amount which is easy to pack into bags
Auto matic stop in the event of straw jamming
Automatic product counting.

Main Technical Variables:

Mode DFCY-4 DFCY-5 DFCY-6
Driving Moto 1.5Kw(Inverter Control) 1.5Kw(Inverter Control) 1.5Kw(Inverter Control)
Processing Speed 200-300Pcs/min 200-300Pcs/min 200-300Pcs/min
Inside Diameter ¢3.8mm ¢4.8mm ¢5.8mm
Length Of Straight Straw 165-245mm 200-260mm 200-260mm
Length of Flexible Straw 150-230mm 185-245mm 185-245mm
Straw Wall Thickness 0.2±0.02mm 0.15±0.02mm 0.15±0.02mm
Top Section Length 30-50mm(Adjustable) 30-50mm(Adjustable) 30-50mm(Adjustable)
Length of flex. Part 8-11mm(Adjustable) 8-11mm(Adjustable) 8-11mm(Adjustable)
Dimension (LxWxH) 1500x1800x1600mm 1500x1800x1600mm 1500x1800x1600mm
