  Your Position :Home >>> Product >>> Film Blowing Machine
SJ-B Series Rotary Machine Head Film Blowing Machine Set(PE Heat-shrinkable) Views:10147

Characteristics:

It is used for blowing high-low pressure polyethylene, which has been widely used for producing laminating film, packing film, agricultural covering film, bag or film for textile and clothing and other packing material. The main motor adopts frequency control of motor speed to improve the speed regulating stability of main motor and save electricity by 30%. The screw and material barrel adopt 38 chrome-molybdenum aluminum which has been nitrogen treated and the traction frame adopts lifting type. No matter what size the film is, big or small, it can achieve the best effect of cooling.

OPTIONAL EQUIPMENT:

1)  AUTO LOADER
2)  EMBOSSING ROLLER
3)  FILM SURFACE TREATER
4)  DIE ROTARY DEVICE
5)  AIR COMPRESSOR
6)  MECHANICS SCREEN CHANGER
7)  UP AND DOWN

Main Technical Variables:

Model

SJ-B50

SJ-B55

SJ-B65

SJ-B65-

Screw Diameter

50mm

55mm

60mm

65mm

Screw Ratio(L/D)

28:1

28:1

28:1

28:1

Screw Speed

10-100r/min

10-100r/min

10-100r/min

10-100r/min

Power of Main Motor

11Kw

15Kw

15-18.5Kw

18.5-22Kw

Max Output

35kg/h

50kg/h

65kg/h

80kg/h

Max.Folding Width of Film

600mm

800mm

1000mm

1200mm

Single-sided Thickness of Film

0.01-0.10mm

0.01-0.10mm

0.01-0.10mm

0.01-0.10mm

Total Power

22Kw

26Kw

30Kw

36Kw

Weight of Machine

2.5T

2.9T

3.4T

3.5T

Overall Dimensions

6200 x 2050 x 4700mm

6800 x 2500 x 5000mm

7200 x 2700 x 5800mm

7300 x 2900 x 5800mm
